LG Genuine Fridge Water Filter ADQ73693901 3650JD8050A 5231JA200B
Based on 2 customers advices.
Push in Connection 1/4" Fits all LG external Fridge Filters
This is LG Genuine Part from LG Electronics Australia
This Filter fits this below model and more.
PART NUMBER SHOWN
ARWF6755 / ADQ73693901 ( Discontinued ) / 3650JD8050A
GC-L197DSL | GC-L197HFS | GC-L197NIS | GC-P197DPL |
GC-P197DPSL | GC-P197HPL | GC-P197STL | GC-P227FSL |
GF-B620SL | GR-D257SL | GR-L197NIS | GR-L197VS |
GR-L197WVS | GR-L207GVZ | GR-L207MSZ | GR-L227STG |
GR-L247DPSL | GR-L247STB | GR-P197NIS | GR-P197WVS |
LG GENUINE EXTERNAL FILTER BY WATER FILTER FORFRIDGE | |||
GR-P227STG | GS9366AEAV | GS-D665BSL | GS-D665PL |
GS-L668PL | GR-L197QQA | GR-L197QTQA | GR-L207GTZ |
GR-L207MGZ | GR-L247GTZ | GR-P197QJA | GR-P197QTJA |
GR-P207TJA | GR-P207TTJA | GR-P227STGA | GR-P247MSZ |
GR-L207TQA | GR-L207TTQA | GR-P197QTJA |
|
GR-L197NIS | GR-L197VS | GR-L197WVS | GR-L227STG |
GR-L247STB | GR-P197NIS | GR-P197WVS | GR-P227STG |
THIS WATER FILTER FITS TO SYSTEM NUMBER BELOW - Mexi Trading ptty LTD | |||
5231JA2010C | 5231JA2010A | 3219JA3001E | 3219JA3001P |
5231JA2003B | 5231JA2012A | 5231JA2012B | ADQ73693901 |
3219JA3001V | 3219JA3001Y | 5231JA2010B |
Features
- Genuine LG ADQ73693901 Cartridge for LG fridge freezers
- LG external inline fridge water filter cartridge
- External inline fridge water filter cartridge for LG fridge freezers
- ' Push Fit ' fitting fridge water filter cartridge
Installation and replacement procedure for the Compatible External fridge water filter
1. Find isolation valve which will be located somewhere on the water supply line to the fridge. Turn it off and to depressurise the system draw a large glass of water from the water outlet at the fridge.
2. Have a bucket and towel ready as there will be a small spillage of water during this process. Remove the old filter by depressing the locking collar at each end of the filter with your thumb nail (or similar) and at the same time pull out the water supply line. Discard the old filter.
3. Take the new filter, making sure the flow direction is correct and insert the inlet side only, the line will go in approx 5 – 10mm and you will feel it hit home.
4. IMPORTANT - Placing the filter in the bucket, turn on the water supply and allow about 5 litres of water to flow through the filter and into the bucket. This will remove any loose carbon fines. Turn off the water supply and connect the line that feeds into the fridge. Turn on the water supply and run approx 2 litres through the system.
5. Complete the Replacement Due sticker and place in a visible area inside the fridge door.
NOTE: The green light changes to orange after five months to indicate that you should soon change the water filter. It changes to red after an additional one month (6 months after the water filter was changed or installed) to indicate that you must change the water filter. If the water filter indicator lights up red, press the ICE TIMER and ICE MODE buttons at the same time for about three seconds to reset the water filter indication light from red to green.
Important: It is essential that operation, maintenance and filter replacement be carried out in accordance with manufacture's recommended procedures and guidelines for this product to perform as advertised. Failure to do so may void warranty
As with all built-in refrigerator water filters, the compatible external fridge water filter does not remove Fluoride.
Note: The filter provides cleaner, fresher water ice.
Important: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. The contaminants or other substances removed or reduced by the water filter device are not necessarily in your water
The LG ADQ73693901 External Water Filters Operating Specifications are as Follows
- Part Number: ADQ73693901
- Flow Rate: 0.5 gpm (1.9 lpm)
- Min / Max Temperature: 30°F - 100°F (1°C - 38°C)
- Max. Pressure: 125 psi (861.8 kPa)
- Capacity: 500 gallons (1,892 L)
- Carbon: Granular Activated Carbon
- Particulate: 20x40mesh, Premium Quality
- Period of Use: 6 months
- Tested and Certified by WQA against NSF/ANSI 42&372 for the reduction of chlorine taste and odor.
